Model
**Skip**
Length : 1150
Width : 648
Height : 515
Capacity : 0.2 m3
Angle of dumping : 57° /47°
Angle from the ground : 10°
***Engine***
Model : BRIGGS & STRATTON
Fuel : gasoline
Rated power : 6.8Kw
rotating speed : 3000-/min
Cylinder : 1
*** Hvdraulic system***
Motor : Big torque motor
Double pump : Gear pump
System pressure : 16MPa
System flow : 12ml/min
Hydraulic oil tank capacity : 19.4L
***Body of machine***
Operating weight : 600kg
Load capacity : 500kg
Fuel tank : 5.5L
Speed : 3.5km/h
