DIMENSIONS

Operating height: 106 in (2695 mm)

Height to bucket hinge pin: 74.8 in (1900 mm)

Height to top: 58.9in (1496 mm)

Overall length with GP bucket: 106 in (2694 mm)

Over length without bucket: 81.5 in (2067 mm)

Wheelbase: 42.5 in (1080 mm)

Overall width: 42 in (1070 mm)

Mini ground clearance: 3.7 in (95 mm)

Angle of departure: 23°

Rated loading capacity: 400 kgs

Kerb weight: 1350 kgs

PERFORMANCE

Ground drive speed

Forward / reverse: 4.7 mph (7.6 km/h)

HYDRAULIC SYSTEM

Working system

Working system pressure: 2610 psi (180 bar)

Working system flow rate: 11.8 gpm (44.8L/min)

Driving system

Driving system pressure: 3625 psi (250 bar)

Driving system flow rate: 18.6 gpm (70.5L/min)

Auxiliary circuit system

Auxiliary circuit pressure: 2610 psi (180 bar)

Auxiliary circuit flow rate: 11.8 gpm (44.8L/min)

POWER

Engine maker: Perkins 403J-11

Fuel type: Diesel

Rating power: 25hp (18.4 kW)

Number of culinder: 3

Displacement: 1.131L

Rated speed: 2800 rpm

FLUID CAPACITIES

Fuel tank capacity: 9.25 gal (35L)

Engine oil: 4.5L

Hydraulic reservoir capacity: 9.25 gal (35L)

BATTERY

Electrical voltage: 12V

Battery type: 45AH

**2 years warranty on motor **

**1 year Warranty on all parts**
