*** Option Included ***
– Close cabin
– A/C
– Heater
– Cold weather starting device
-Joystick control
– Stander Bucket
-Bobcat type quick coupler
– hydraulic self-leveling system
*** Specification***
– Rated Operating Capacity(Kg) : 1050
– Tipping load(Kg) : 2100
– Bucket Capacity(m3) : 0.5
– Lifting Force(Kg) : 2730
– Hydraulic Pump Flow(L/min) : 75/115
– Engine power(hp) : 75
– Weight(Kg) : 3500
– Max. Travel Speed(km/h) : 8/16
– Grade ability(° ) : 20
– Tire : 12-16.5
– Fuel/hyd. Oil capacity(L) : 90/90
*** Dimensions ***
– Height at Maximum Extension : 4070mm
– Hinge Pin Height : 3150mm
– Total Height : 2160mm
– Length with Bucket : 3580mm
– Length without Bucket : 2880mm
– Width with Bucket : 1880mm
– Track Width : 1500mm
– Wheelbase : 1115mm
– Ground Clearance : 205mm
– Dumping Angle ° : 40
– Dumping Height : 2450mm
– Maximum Reach : 700mm
**2 years warranty on motor **
**1 year Warranty on all parts**
