*** ENGINE***
Emission Standard : Tier 5/ EPA 4
Make /Model : KUBOTA
Power /Rotation speed : 14.1kw(20HP)@2000rpm
Number of cylinder : 3
*** TRACK SYSTEM***
Maximum Travel speed : 3.5km/h
Width of track shoe(Rubber & steel track) : 230mm/ 9 inch
Number of track shoe per side : 38 pcs
Number of upper roller/ bottom roller (perside) : 0/4
*** PERFORMANCE PARAMETER***
Standard bucket capacity : 0.06m3
Swing speed : 10~12 rpm
Max. Grade ability : 35°
Max. Bucket digging force : 14KN
Max. Arm digging force : 10KN
Hydraulic system pressure : 18Mpa
Machine weight : 2500kg/ 5500 LBS
*** MACHINE SIZE ***
Overall dimension (L*W*H) : 3865mm*1050mm*2270mm (152x 41×89 inch)
Axle base(Track length on ground) : 1230mm/ 48.4 inch
Track gauge : 820mm/ 32.2 inch
Min.Ground clearance : 210mm/ 8.2 inch
Swing radius at tail : 1125mm/ 44.2 inch
*** WORKING RANGE***
Max. Digging height : 3365mm/ 132.4 inch
Max. Dumping height : 2385mm/ 93.8 inch
Max. Digging depth : 2050mm/ 80.7 inch
Max. Vertical digging depth : 1725mm/ 67.9 inch
Max. Digging radius : 3860mm/ 144.8 inch
Min .swing radius : 1720mm/ 67.7 inch
Max. Lifting height of blade : 230mm/ 9 inch
Max. Cutting depth of blade : 275mm/ 10.8 inch
Boom swing angle(Left) : 75°
Boom swing angle(Right) : 45°
